384V High Voltage Lithium Ion Battery With BMS & LCD Display
Product introduction:
This product is composed of high quality lithium iron phosphate core (series-parallel connection) and advanced BMS management system. It can be used as independent DC power supply or as "basic unit" to form a variety of energy storage lithium battery power supply systems. It has high reliability and long life. products developed for applications such as power grid energy storage, industrial and commercial energy storage, home high voltage energy storage, high voltage UPS, and data room.
The product adopts modular design, higher integration, saving installation space; adopts high performance lithium iron phosphate cathode material, good core consistency, design service life of more than 10 years; one-key switch machine, front operation, front wiring, convenient installation and maintenance, easy operation; various functions, with single over-voltage / under-voltage, total voltage under-voltage / over-voltage, charge / discharge over-current, high temperature, low temperature, insulation and short circuit protection and recovery functions; strong compatibility, seamless docking with UPS ,photovoltaic power generation and other main equipment; communication interface forms, CAN/RS 485 and so on can be customized according to customer needs, convenient system remote monitoring and flexible use. High energy, low power lithium electric equipment, achieve higher energy supply, lower energy consumption, and reduce environmental pollution; adopt all-round, multi-level battery protection strategy and fault isolation measures to ensure the safe operation of the system.
Performance characteristics:
● Small size and light weight
● Maintenance-free
● Environmental protection and pollution-free materials, no heavy metals, green and environmental protection
● The standard cycle life exceeds 5000 times
● Accurately estimate the state of charge of the battery pack, that is, the remaining power of the battery, to ensure that the power of the battery pack is maintained within a reasonable range
● Built-in BMS management system with comprehensive protection and monitoring and control functions
| Model |
GBP-384100 |
GBP-384200 |
GBP-384300 |
| Type of core |
Lithium iron phosphate |
| Rated energy (KWH) |
40 |
80 |
120 |
| Nominal capacity (AH) |
100 |
200 |
300 |
| Nominal voltage (VDC) |
384 |
| Operating voltage range (VDC) |
312-450 |
| Recommended Charge Voltage (VDC) |
420 |
| Recommended discharge cutoff voltage (VDC) |
366 |
| Standard charging current (A) |
50 |
80 |
120 |
| Maximum continuous charge current(A) |
100 |
200 |
300 |
| Standard discharge current (A) |
50 |
80 |
120 |
| Maximum continuous discharge current (A) |
100 |
200 |
300 |
| Working temperature |
-20~65℃ |
| Protection level |
IP20 |
| Communication interface |
RS485/CAN two choose one |
| Reference Weight (Kg) |
500 |
1000 |
1500 |
| Reference size (D*W*H mm) |
530*550*2020 |
(625*550*1600)*2 |
(625*550*1600)*3 |
